CT Hone, Inc. horizontally honed this 4130 steel sleeve, measuring 147″ in length, with an O.D. of 3.500″. The finished I.D. was 2.750″ with .025″/.030″ of stock removed, and had a material microfinish of 63. Utilizing our long/horizontal honing equipment, as well as Sunnen tooling, we easily met the required tolerances of ± .001″. We relied on the customer supplied operation sheet and 2D CAD drawing to ensure the sleeve met customer specifications.
To learn more about this I.D. honing project, please see the details below. For more information about our other services, please contact CT Hone, Inc.
Long Steel Sleeve Project Highlights
- Product Name
-
I.D. Honing of a Long Steel Sleeve
- Product Description
-
We had to hone this sleeve for use in the commercial industry.
- Capabilities Applied/Processes
-
Long/Horizontal I.D. Honing
- Equipment Used to Hone Part
-
Custom Long/Horizontal Honing Machine & Sunnen Tooling
- Overall Part Dimensions
-
I.D. of Honed Hole:
- 2.750″
- Length: 147″
- O.D.: 3.500″
- Tightest Tolerances
-
± .001″
- Material of Component
-
4130 Steel
- Maximum Material Finish
-
63 Microfinish
- In Process Testing/Inspection Performed
-
- Dimensional inspection with Sunnen gages
- Surface finish inspection with Bendix profilometer
- Industry for Use
-
Commercial
- Standards Met
-
- Customer supplied operation sheet
- 2D CAD drawing & specifications
